TDOBIY630P


Features

  • Three 1/2.8” 2Megapixel progressive scan Exmor R CMOS

  • Support H.265&H.264 dual encoding

  • Smart triple streams supported

  • Max 25/30fps@4096×832

  • Support 180-degree panoramic view

  • Day/Night(ICR), 3DNR, AWB, AGC, BLC,WDR

  • Smart detection

  • Intelligent Function

  • Max. IR LEDs length 98ft

  • IP67, IK10, PoE+

  • Optional accessories: PFA120, PFA150, PFA151

Model

TDOBIY630P

Camera

Image Sensor...Three ½.8” 2Megapixel progressive scan CMOS

Effective Pixels................................................ 4096(H)x832(V)

RAM/ROM.........................................................1024MB/128MB

Scanning System..................................................Progressive

Electronic Shutter Speed..............Auto/Manual, 1/3˜1/100000s

Minimum Illumination..............0.007Lux/F1.8(Color,1/3s,30IRE)

                                                                 0.05Lux/F1.8(Color,1/3s,30IRE)

                                                                 0Lux/F1.8(IR on)

S/N Ratio........................................................More than 50dB

IR Distance................................................Distance up to 98ft

IR On/Off Control..................................................Auto/Manual

IR LEDs.....................................................................................8



Lens

Lens Type.......................................................................Fixed

Mount Type............................................................... Board-in

Focal Length................................................................3.6mm

Max. Aperture...................................................................F1.8

Angle of View.....................................................H: 180°, V:44°

Optical Zoom.....................................................................N/A

Focus Control.................................................................Fixed

Close Focus Distance........................................................N/A



DORI Distance

Detect.............

........52m(171ft)

Observ.....................21m(69ft)

Recognize................10m(33ft)

Identify.....................5m(16ft)



Pan/Tilt/Rotation

Pan/Tilt/Rotation Range..................Pan:0°~360°; Tilt: 0°~90°;                                                                              Rotation: 0°~360°



Intelligence

IVS...................Tripwire, Intrusion, Object Abandoned/Missing

Advanced Intelligent Functions...........Face Detection, People                                                                           Counting, Heat Map, E-PTZ



Video

Compression............................... H.265+/H.265/H.264+/H.264

Streaming Capability...............................................3 Streams

 Resolution4096×832/3840×780/2560×520/1280×260/1024×208

Frame Rate......................Main Stream: 4096×832 (1~25/30fps)

                                                       Sub Stream: 1024×208 (1~25/30fps)

                                                       Third Stream: 1280×260 (1~25/30fps)

Bit Rate Control........................................................CBR/VBR

Bit Rate.................................................H.265: 4kbps~10Mbps

                                                                                     H.264: 8kbps~16Mbps

Day/Night.............................................Auto (ICR) / Color / B/W

BLC Mode..........................................BLC / HLC / WDR(120dB)

White BalanceAuto/Natural/Street Lamp/Outdoor/Manual

Gain ControlAuto/Manual

Noise Reduction3D DNR

Motion Detection...........................Off / On (4 Zone, Rectangle)

Region of Interest...........................................Off / On (4 Zone)

Electronic Image Stabilization (EIS)....................................N/A

Smart IR.....................................................................Support

Defog ................................................................................N/A

Digital Zoom.......................................................................16x

Flip....................................................................................N/A

Mirror................................................................................ N/A

Privacy Masking............................. Off / On (4 Area, Rectangle)



Audio

Compression...................................G.711a/G.711Mu/AAC/G.726



Network

EthernetRJ-45 (100/1000Base-T)

ProtocolHTTP;HTPPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;DHCP;DNS;DDNS;

PPPOE;IPv4/v6;QoS;UPnP;NTP;Bonjour;802.1x;Multicast;ICMP;IGMPSNMP

Interoperability..............................................ONVIF, PSIA, CGI

Streaming Method......................................Unicast / Multicast

Max. User Access........................................10 Users/20 Users

Edge Storage............................ NAS

                                                                    Local PC for instant recording

                                                                    Micro SD card 128GB

Web Viewer.................................... IE, Chrome, Firefox, Safari

Management Software.......................... TD SMS, DSS, Easy4ip

Smart Phone........................................................IOS, Android



Certifications



CE ................................................................(EN 60950:2000)

UL:........................................................................ UL60950-1

FCC: .....................................................FCC Part 15 Subpart B

Interface

Video Interface..............................1 Port(For adjustment only)

Audio Interface............................................1/1 channel In/Out

RS485...............................................................................N/A

Alarm.................................................2 channel In: 5mA 5VDC

                                                      1 channel Out: 1A 30 VDC / 0.5 50VAC



Electrical

Power Supply........................... AC24V, PoE+ (802.3at)(Class 4)

Power Consumption.......................................................<23W



Environmental

Operating Conditions..............-40°C ~ +60°C (-40°F ~ +140°F),                                                                    Less than 95% RH

Storage Conditions..................-40°C ~ +60°C (-40°F ~ +140°F),                                                                    Less than 95% RH

Ingress Protection............................................................IP67

Vandal Resistance............................................................ IK10



Construction

Casing............................................................................Metal

Dimensions...298.3mm×172.5mm×120.5mm (11.74″×6.79″×4.74″)

Net Weight....................................................... 2.60kg (5.73lb)

Gross Weight..................................................... 3.41kg (7.52lb)
