TDODIS6F


Features

  • 1/1.8” 6Megapixel progressive scan CMOS

  • H.264 &MJPEG dual-stream encoding

  • Max 25/30fps@6.0M(3072×2048)

  • Multiple De-wrap Mode: Original ,Panoramic, Double Panoramic,1+3,Eptz,4 pictures

  • DWDR, Day/Night(ICR), 3DNR,ROI,AWB, AGC, BLC

  • Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS

  • Max. IR LEDs Length 30FT

  • 1/1 channel in/out(Built in Mic)

  • Micro SD memery,IP67,IK10,PoE

  • Optional accessories: PFA100, PFB302S, PFA132, PFA152-E, PFA151

Model

TDODIS6F

Camera

Image Sensor............1/1.8” 6Megapixel progressive scan CMOS

Effective Pixels...............................................3072(H)x2048(V)

Scanning System..................................................Progressive

Electronic Shutter Speed...............Auto/Manual 1/3(4)~1/10000

Min. Illumination...............0.01Lux/F2.0(Color),0Lux/F2.0(IR on)

                                                      S/N RatioMore than 50dB

Video Output.....................................................................N/A



Camera Features

Max. IR LEDs Length.......................................................30FT

Day/Night..............................................Auto(ICR) / Color / B/W

Backlight Compensation.............................. BLC/ HLC/ DWDR

White Balance..................................................... Auto/Manual

Gain Control.........................................................Auto/Manual

Noise Reduction.................................................................3D

Privacy Masking..................................................Up to 4 areas



Lens

Focal Length...............................................................1.55mm

Max Aperture....................................................................F2.0

Focus Control.............................................................. Manual

Angle of View.....................................................185°/185°/185°

Lens Type....................................................................Manual

Mount Type.......................................................Board-in Type



Video

Compression...............................H.264H/H.264/MJPEG/JPEG

Resolution.....6M(3072×2048)/3M(2048×1536)/1080P(1920×1080)

Frame Rate ................................Main Stream6M/(1 ~ 25/30fps)

                                                                 Sub StreamD1/CIF(1 ~ 25/30fps)

Bit Rate.......................................................40Kbps~8192Kbps

De-wrap Mode........................Original ,Panoramic, Double                                                                          Panoramic,1+3,Eptz,4 pictures

Audio

Compression...............................................G.711a/G.711u/PCM

Interface....................................1/1 channel In/Out(Built in Mic)



Network

Ethernet............................................RJ-45 (100/1000Base-T)

Wi-Fi.................................................................................N/A

Protocol.......HTTP,TCP,ARP,RTSP,RTP,UDP,RTCP,SMTP,FTP,DHCP,DNS,DDNS,PPPOE,IPv4/v6,SNMP,QoS,UPnP,NTP

Compatibility...................................................ONVIF PSIA CGI

Max. User Access .......................................................20users

Smart Phone................iPhone, iPad, Android, Windows Phone



Auxiliary Interface

Memory Slot............................................Micro SD, up to 64GB

RS485............................................................................... N/A

Alarm.......................................................... 2/1 channel In/Out

PIR Sensor Range..............................................................N/A



General

Power Supply...........................................DC12V, PoE (802.3at)

Power Consumption........................................................<11W

Working Environment.............-30°C~+60°C, Less than 95%RH

Ingress Protection............................................................IP67

Vandal Resistance............................................................ IK10

Dimensions...............................................Φ150mm x 50.7mm

Weight.....................................0.58kg(0.86kg with packaging )
