•  8MP, 1/2.8" CMOS image sensor, low illuminance, high image definition

• Outputs max. 8MP (3840 × 2160) @25/30 fps

• H.265 codec, high compression rate, ultra-low bit rate

• Built-in warm light and IR LED, max IR distance: 30 m

• ROI, SMART H.264+/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments

• Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

• Built-in mic

• Intelligent detection: Intrusion, tripwire

Image Sensor ...................... 1/2.8" CMOS

Effective Pixels ...................... 3840 (H) × 2160 (V)

ROM ...................... 128 MB

RAM ...................... 512 MB

Scanning System ...................... Progressive

Electronic Shutter Speed ...................... Auto/Manual 1/3 s–1/100,000 s

Min. Illumination ...................... 0.004 lux@F1.0 (Color, 30 IRE) 0.0004 lux@F1.0 (B/W, 30 IRE) 0 lux (illuminator on)

IR Distance ...................... 30 m (98.43 ft) (IR), 30 m (98.43 ft) (warm light)

IR On/Off Control ...................... Auto/Manual

Illuminator Number ...................... 1 (IR LED), 1 (warm light)

​

Lens Type ...................... Fixed-focal

Mount Type ...................... M12

Iris Type ...................... Fixed

​

Power Supply ...................... 12V DC/PoE (802.3af)

Power Consumption ...................... Basic: 5.2 W (12 VDC); 5.5 W (PoE) Max. (pulling stream+warning light+speaker+warm light on): 9.2W (DC12 V) 10.2 W (POE)

Casing ...................... Metal

Dimensions ...................... 110.9 mm × 122.0 mm (4.37" × 4.80")

Net Weight ...................... 745 g (1.64 lb)

Gross Weight ...................... 915 g (2.02 lb)

​

​

​

​

​

​

​
